Corsair MP700 PRO 1TB NVMe M.2 SSD

Capacity options

Maximum sequential read

Maximum sequential write

Drive format

Capacity for the Installed Library

The available 1 TB / 2 TB capacity options let you choose the drive around the space needed for the system. Plan room for the operating system, applications, game updates and working files when choosing the drive. Some of the labelled capacity is used for formatting and drive functions, so usable space depends on the operating environment. Keep a separate backup arrangement for files that need to be retained.

Sequential Transfer Performance

Sequential read: 1 TB: 11700 MB/s; 2 TB: 12400 MB/s. Sequential write: 1 TB: 9600 MB/s; 2 TB: 11800 MB/s. These are manufacturer maximum figures under the specified test conditions. Actual transfers depend on the host hardware, software, available cache, temperature and workload. Use the capacity-specific figures when comparing this drive with another option, particularly where a larger version of the same family has a different write rating.

Match the Storage Interface

The drive uses PCIe 5.0 x4, NVMe 2.0 in a M.2 2280 NVMe format. Check that the intended M.2 slot accepts a 2280-length PCIe NVMe drive and supports the required interface. The host connection determines the available link speed, so confirm the system specification before planning an upgrade.

The CORSAIR MP700 PRO with Air Cooler Hardware

MP700 PRO combines 3D TLC NAND with a PCIe Gen 5 NVMe 2.0 platform. This air-cooled version includes active cooling, and its 1 TB and 2 TB options carry different transfer ratings. Compare the selected capacity’s read, write and endurance values when choosing the drive for the system. These characteristics describe the selected drive family and capacity. Use them alongside the interface and performance figures when choosing storage for a desktop or compatible notebook. Keep any service or firmware work within the manufacturer’s supported procedure and maintain a backup of important files before changing a storage installation.

Capacity-Specific Write Endurance

The rated write endurance is 1 TB: 700 TBW; 2 TB: 1400 TBW. TBW means terabytes written and describes a tested write-workload rating. It is not the same as usable capacity or a guaranteed number of years of operation. Consider the expected write workload when choosing a drive for application files, game installations, recordings or project data.

Family

CORSAIR MP700 PRO with Air Cooler

Capacity options

1 TB / 2 TB

Form factor

M.2 2280

Which capacity is supplied?

Select the required available variation: 1 TB / 2 TB.

What interface does this SSD need?

PCIe 5.0 x4, NVMe 2.0; use a suitable M.2 2280 PCIe NVMe slot.

What are its sequential-speed ratings?

Sequential read: 1 TB: 11700 MB/s; 2 TB: 12400 MB/s. Sequential write: 1 TB: 9600 MB/s; 2 TB: 11800 MB/s. Actual performance depends on the host and workload.

What cooling or fitting checks are needed?

The air-cooled version includes its active cooler. Check clearance around the complete assembly and follow the cooler’s connection instructions during installation.
