NZXT H1 V2 Mini ITX Case with PSU and AIO
NZXT

NZXT H1 V2 Mini ITX Case with PSU and AIO

The NZXT H1 V2 combines a vertical Mini-ITX case with an installed 750 W SFX Gold power supply, a 140 mm AIO CPU cooler and a PCIe 4.0 x16 riser. The integrated components organise the core power, cooling and graphics connection within the compact frame.

Color

SKU: NZXT-H1-V2

Regular price 135.500 KWD

or 4 payments of 33.875 KWD with

Pay with card & save

KNET Mastercard Gateway
129.000 KWD Save 6.500 KWD
Sold out

Overview

NZXT H1 V2

NZXT H1 V2 — product view

A Mini-ITX Case with Integrated Power, Cooling and Riser

The NZXT H1 V2 combines a vertical Mini-ITX case with an installed 750 W SFX Gold power supply, a 140 mm AIO CPU cooler and a PCIe 4.0 x16 riser. The integrated components organise the core power, cooling and graphics connection within the compact frame.

750 W Gold

Integrated SFX PSU

140 mm AIO

Integrated CPU cooler

PCIe 4.0 x16

Supplied riser

Mini-ITX

Motherboard format

NZXT H1 V2 — product view

A Vertical Mini-ITX Layout

The H1 V2 is designed for a Mini-ITX motherboard, with the graphics card arranged alongside the main system through the supplied riser. The vertical tower separates the component areas within its compact body. Choose the motherboard, graphics card and memory around the case’s installation sequence and the integrated cooling hardware.

A 750 W Gold Power Supply Included

The integrated SFX power supply is a fully modular 750 W unit with 80 PLUS Gold certification. Its supplied power leads serve the motherboard, processor, graphics card and storage connections documented for the case. Check the selected graphics hardware’s power requirements and connectors before completing the component list.

An Integrated 140 mm CPU Cooler

A 140 mm all-in-one liquid CPU cooler and an Aer P static-pressure PWM fan are installed as part of the case arrangement. Use the socket-specific mounting parts supplied with the actual unit, then follow the bracket and tube-positioning instructions. The cooler and motherboard are installed as a coordinated compact assembly.

PCIe 4.0 Graphics Connection

The supplied PCIe Gen 4-compatible x16 riser connects the motherboard to the separate graphics-card position. GPU length clearance is 324 mm and maximum card thickness is 58 mm. Compare the complete cooler and expansion-bracket dimensions with these limits, including space for the card’s power plugs and cable route.

Dedicated GPU Exhaust and Fan Control

A 92 mm PWM fan provides the GPU-side exhaust, complementing the CPU cooler’s intake arrangement. The integrated controller provides two PWM fan channels. Keep the ventilation paths clear when arranging the pre-routed wiring, and connect the fan and control leads according to the H1 V2 guide.

NZXT H1 V2 — product view

Motherboard format

Mini-ITX

Integrated PSU

750 W SFX; fully modular; 80 PLUS Gold

Integrated CPU cooler

140 mm AIO with 140 mm Aer P PWM fan

Storage and Socket Installation

Two 2.5-inch SSD positions provide storage mounting inside the case, with tool-free trays for the supported drives. The guide covers Intel LGA 115x/1200/1700 and AMD AM4/AM5 mounting with the appropriate parts. Confirm the supplied kit for the chosen socket and follow the prescribed component-installation order in the compact frame.

Complete Your Workspace

Explore PC Cases to compare suitable options and complete your setup.

Frequently Asked Questions

Which motherboard formats fit?

Mini-ITX.

What graphics-card length is supported?

324 mm.

What power supply is included?

750 W SFX; fully modular; 80 PLUS Gold.

What CPU cooler is included?

140 mm AIO with 140 mm Aer P PWM fan.

Is a graphics riser supplied?

PCIe Gen 4-compatible x16.

Build Your Setup with AX Store Kuwait

Explore computers, displays and accessories for your workspace at AX Store Kuwait. For help choosing the right model or checking an accessory, contact AX Store.

THE DETAILS

Technical specifications

Case Hardware

Model

NZXT H1 V2

Case size

Mini Tower

Motherboard support

Mini-ITX

Motherboard format

Mini-ITX

Integrated PSU

750 W SFX; fully modular; 80 PLUS Gold

Integrated CPU cooler

140 mm AIO with 140 mm Aer P PWM fan

Included riser

PCIe Gen 4-compatible x16

Maximum GPU length

324 mm

Maximum GPU thickness

58 mm

GPU exhaust fan

92 mm PWM

Fan controller

2-channel PWM

SSD positions

2 × 2.5-inch

Expansion slots

2

Socket fit

Intel LGA 115x / 1200 / 1700; AMD AM4 / AM5, with appropriate mounting parts
