Corsair RM1000e 1000W Gold Modular Power Supply Unit
Corsair

Corsair RM1000e 1000W Gold Modular Power Supply Unit

CORSAIR RM1000e (CP-9020250) combines 1000 W continuous output with 80 PLUS Gold certification and fully modular cables. Its ATX format and model-specific connections provide a power-supply option for a compatible desktop build, with A 120 mm rifle-bearing fan supports Zero RPM operation at suitable lower loads.

SKU: CP-9020250-UK

Regular price 68.500 KWD

or 4 payments of 17.125 KWD with

Pay with card & save

KNET Mastercard Gateway
65.000 KWD Save 3.500 KWD

Overview

CORSAIR RM1000E (CP-9020250)

CORSAIR RM1000e (CP-9020250) product view

1000 W ATX Power with 80 PLUS Gold Efficiency

CORSAIR RM1000e (CP-9020250) combines 1000 W continuous output with 80 PLUS Gold certification and fully modular cables. Its ATX format and model-specific connections provide a power-supply option for a compatible desktop build, with A 120 mm rifle-bearing fan supports Zero RPM operation at suitable lower loads.

1000 W

Rated output

80 PLUS Gold

Efficiency

ATX

PSU format

Fully modular

Cable layout

CORSAIR RM1000e (CP-9020250) product view

Power for the Complete Configuration

The unit is rated for 1000 W continuous output. Choose the supply around the complete system’s power requirements, including the processor, graphics card, drives and expansion hardware. The output rating describes its supply capacity; the actual power drawn by the computer depends on the installed components and the workload. Check both the power requirement and the required connectors when planning an upgrade.

80 PLUS Gold Efficiency

80 PLUS Gold certification describes the power supply’s conversion efficiency under the certification test conditions. It complements the model’s output rating when selecting a supply for the intended system. Efficiency varies with input conditions and load, so the certification should be read alongside the electrical ratings and the complete configuration rather than as a fixed efficiency at every operating point.

Connections Chosen for This Model

The fully modular cable layout lets you connect the leads required by the installed hardware and keep unused leads outside the case. Connections include one 24-pin motherboard connector, two 4+4-pin CPU connectors, six PCIe 6+2-pin connectors, seven SATA power connectors and four peripheral connectors. Use the appropriate motherboard, CPU and graphics connections for each component. Keep the PSU’s own modular cable set with the unit, and use replacement leads only when the manufacturer confirms compatibility with this exact PSU and cable interface.

Cooling That Follows the Load

A 120 mm rifle-bearing fan supports Zero RPM operation at suitable lower loads. Leave the case’s PSU intake and exhaust routes clear and position the supply according to the case guidance. Fan speed and operating noise depend on the system load, temperature and airflow around the enclosure. A low-load fan-stop mode, where provided, works as part of that control behaviour rather than guaranteeing silent operation in every workload.

Check the Case and Cable Clearance

Its ATX enclosure measures 160 × 150 × 86 mm. Match the PSU bay, mounting points and cable-routing space with the case before installation. Account for the connected plugs and their routing space as well as the metal enclosure itself. Arrange the cables so that the case panel can close without placing strain on the connections, and retain access to the power switch and AC inlet in the finished system.

CORSAIR RM1000e (CP-9020250) product view

Model

CORSAIR RM1000e (CP-9020250)

Rated output

1000 W continuous output

Efficiency certification

80 PLUS Gold

The Details of This Power Supply

This RM1000e uses the CORSAIR Type 4 cable interface and supports Modern Standby. The design and connection layout should be considered together when choosing the unit for a new build or a replacement. Compare the listed electrical ratings, physical format and cables with the planned hardware, then follow the supplied installation guidance when assembling the completed system.

Complete Your Workspace

Explore Power Supplies to compare suitable options and complete your setup.

Frequently Asked Questions

What is the rated output?

1000 W continuous output.

Which efficiency certification does it have?

80 PLUS Gold.

How do I check case compatibility?

Its ATX enclosure measures 160 × 150 × 86 mm. Match the PSU bay, mounting points and cable-routing space with the case before installation.

What power connections are available?

Connections include one 24-pin motherboard connector, two 4+4-pin CPU connectors, six PCIe 6+2-pin connectors, seven SATA power connectors and four peripheral connectors.

Can modular cables be shared between different PSUs?

Only use a replacement cable when its manufacturer confirms compatibility with this exact PSU and cable interface. Keep the unit’s supplied modular cable set with the PSU.

Build Your Setup with AX Store Kuwait

Explore computers, displays and accessories for your workspace at AX Store Kuwait. For help choosing the right model or checking an accessory, contact AX Store.

THE DETAILS

Technical specifications

Power Supply Specifications

Model

CORSAIR RM1000e (CP-9020250)

Rated output

1000 W continuous output

Efficiency certification

80 PLUS Gold

Physical form factor

ATX

Cable modularity

Fully modular

Dimensions

160 × 150 × 86 mm

Power connections

Connections include one 24-pin motherboard connector, two 4+4-pin CPU connectors, six PCIe 6+2-pin connectors, seven SATA power connectors and four peripheral connectors.

Cooling

A 120 mm rifle-bearing fan supports Zero RPM operation at suitable lower loads.

Design features

This RM1000e uses the CORSAIR Type 4 cable interface and supports Modern Standby.

Manufacturer part

CP-9020250-UK

AC input

100–240 V AC; 47–63 Hz

+12 V rail

83.3 A; 1000 W

Electrical interface

ATX12V 2.53

Cable interface

CORSAIR Type 4
