Kingston Fury Beast 16GB DDR4 3200MT/s Memory Kit

Total supplied capacity

Rated profile data rate

Rated CAS latency

Supplied modules

Capacity and Module Arrangement

The 16 GB total is supplied as 2 matched 8 GB modules. Install the supplied modules together in the slots recommended by the motherboard manual, allowing the platform to use its supported channel arrangement. Consider the working-memory requirements of the applications you run alongside the space already installed in the computer. A matched kit provides its stated total across the supplied modules; it is not that capacity per stick.

A Rated 3200 MT/s Profile

The rated memory profile is up to 3200 MT/s, with 16-18-18 timings at 1.35 V. These values describe the tested profile rather than an automatic setting on every computer. Choose a processor and motherboard that support the intended memory configuration, then use the board’s documented profile controls to configure the system.

Profile Support and Startup Settings

Intel XMP 2.0 is the supported profile format for this model. The default SPD/JEDEC configuration is DDR4-2400 CL17-17-17 at 1.2V. The computer may start at its default memory settings before a profile is selected. The available operating speed depends on the processor’s memory controller, installed BIOS, module population and the exact kit support offered by the board.

A DDR4 Desktop DIMM Match

This is DDR4 desktop memory in the 288-pin DIMM format. Match both the memory generation and physical module type with the motherboard before installation. DDR4 and DDR5 use different electrical arrangements and cannot be interchanged. Check the board’s memory support list and maximum supported module capacity when selecting the kit for the complete platform.

Heat Spreader and Build Clearance

The Beast RGB Special Edition design includes RGB lighting and a heat spreader, with a specified overall height of 45.8 mm. Check the space around the DIMM slots, particularly where a large CPU cooler or its fan extends over the memory. Account for the complete module and heat-spreader height when planning that arrangement. A suitable case airflow path also helps the surrounding motherboard and cooling hardware work as intended during longer sessions.

Manufacturer part

KF432C16BWAK2/16

Product family

Kingston FURY Beast RGB Special Edition

Memory generation

DDR4

How many modules are supplied?

2 × 8 GB. The total kit capacity is 16 GB.

Will it automatically run at the rated data rate?

The default configuration is DDR4-2400 CL17-17-17 at 1.2V. Using the up-to 3200 MT/s profile requires compatible hardware and appropriate BIOS configuration.

Which profile format is supported?

Intel XMP 2.0.

What are the rated timings and voltage?

16-18-18 at 1.35 V.

Can it fit a DDR5 motherboard?

No. This model requires DDR4 desktop DIMM support. Check the exact kit and module capacity against the motherboard’s compatibility guidance.
