ASUS ROG Rapture GT-BE98 BE25000 Quad-Band WiFi-7 Gaming Router
ASUS ROG Rapture GT-BE98 BE25000 Wi-Fi 7 gaming router with AiMesh support, wired Ethernet connections, Adaptive QoS and AiProtection Pro. See the specifications for the exact band layout, maximum link rates and port configuration.
Overview
ASUS ROG RAPTURE GT-BE98
ASUS ROG Rapture GT-BE98
ASUS ROG Rapture GT-BE98 combines Wi-Fi 7 wireless networking with BE25000-class radio specifications and gaming-focused management tools. Its wired interfaces, processor and AiMesh support give you several ways to arrange a home network around compatible devices. Choose the model by its band layout and port speeds, then configure the connection around your own internet service and local equipment. Explore this model at AX Store in Kuwait.
Wi-Fi 7
Wireless Generation
BE25000
Wireless Speed Class
2.6 GHz Quad Core
Processor
10 GbE
Fastest Ethernet Port
Wireless Bands for Compatible Devices
GT-BE98 combines 2.4 GHz, two 5 GHz bands and a 6 GHz band with 4×4 transmit/receive on each. Listed maximum link rates are 1376 Mbps, 5764 Mbps on each 5 GHz band and 11529 Mbps on 6 GHz. Wi-Fi 7 features include 4096-QAM and channel widths up to 320 MHz for compatible devices and supported regional operation.
Wired Connections Around Your Setup
The wired layout includes a 10G WAN/LAN port, a 2.5G WAN/LAN port, a separate 10G LAN port, three 2.5G LAN ports and one Gigabit LAN port. USB 3.2 Gen 1 and USB 2.0 are also provided. This range of interfaces lets you plan high-speed local connections alongside an internet uplink and other supported network equipment.
Hardware and Physical Design
A 2.6 GHz quad-core processor works with 2 GB of RAM and 256 MB of flash. Eight external antennas form part of the quad-band design. ASUS lists dimensions of 350.41 × 350.41 × 220.6 mm and a weight of 2000 g, giving you concrete measurements to check before choosing a position for the router and its antennas.
Gaming and Traffic Management
Game Boost, OpenNAT and a gaming port sit alongside Adaptive QoS and traffic monitoring. These tools provide ways to prioritize devices and review network activity within a busy gaming setup. Configure the options around your own applications, then use the available traffic information to understand how the connection is shared when several devices are active at once.
Expand with Compatible AiMesh Equipment
AiMesh support allows the router to work as a primary AiMesh router or a node in a compatible ASUS mesh network. It also supports access point operation. Choose the mode that matches your existing equipment and intended layout, then place the router where the wireless connection and wired uplink can serve the devices you want to connect.
Network Controls in One Place
AiProtection Pro, parental controls and guest-network settings are listed in the router’s features. VPN client and server options add ways to configure supported remote connections. Wireless figures are maximum link rates; actual throughput depends on clients and network conditions. Available bands and channel widths also depend on regional settings, so select the supported options during setup.
Match the Network Device to Your Connection
Check the required wired or wireless connection, power arrangement and coverage needs. Confirm the intended role and compatibility with the existing network before choosing another device. Compare related options such as ASUS ZenWiFi XD5 AX3000 Whole-Home Mesh WiFi, 3-Pack White or ASUS USB-N10 NANO B1 Wi-Fi Dongle, 150Mbps, keeping the exact model and configuration in the decision. For the wider setup, explore Syntech USB C Male to USB 3.0 Adapter, 2 Pack and check the connection, size or mounting requirements before pairing accessories. Browse the ASUS range at AX for more choices.
ASUS ROG Rapture GT-BE98 Setup Choices
Check the required wired or wireless connection, power arrangement and coverage needs. Confirm the intended role and compatibility with the existing network before choosing another device.
Frequently Asked Questions
Which wireless standards and bands are supported?
Network Standard: WiFi 6 (802.11ax); WiFi 7 (802.11be); IEEE 802.11a; IEEE 802.11b; IEEE 802.11g; IEEE 802.11n; IEEE 802.11ac; IPv4; IPv6. Operating Frequency: 2.4 GHz / 5 GHz / 6 GHz. Band availability depends on local regulations and compatible client devices.
What do the wireless speed-class figures mean?
This model is listed in the BE25000 wireless class. 2.4GHz BE: 4x4 (Tx/Rx) 4096 QAM 20/40MHz, up to 1376Mbps; 5GHz-1 BE: 4x4 (Tx/Rx) 4096 QAM 20/40/80/160MHz, up to 5764Mbps; 5GHz-2 BE: 4x4 (Tx/Rx) 4096 QAM 20/40/80/160MHz, up to 5764Mbps; 6GHz BE: 4x4 (Tx/Rx) 4096 QAM 20/40/80/160/320MHz, up to 11529Mbps. These are wireless link-rate figures, rather than a guaranteed internet download rate.
Which Ethernet and USB ports are available?
1 x 10Gbps for WAN/LAN 1 x 2.5Gbps for WAN/LAN 1 x 10Gbps for LAN 3 x 2.5Gbps for LAN 1 x RJ45 10/100/1000Mbps for LAN 1 x USB 3.2 Gen1 1 x USB 2.0.
Which operating modes and mesh functions are listed?
Operating Mode: Router(AiMesh router), AiMesh node, Access point, Repeater, Media bridge. AiMesh: AiMesh; • Primary AiMesh Router; • AiMesh Node.
What processor and memory are specified?
Processor: 2.6GHz quad-core processor. Memory: 256 MB Flash and 2 GB RAM.
Build Your Setup with AX Store
Explore computers, displays and accessories for your workspace at AX Store. For help choosing the right model or checking an accessory, contact AX Store.
Compare TP-Link AC1900 Wireless Dual Band Gigabit Router, 600Mbps & 1300Mbps. Match the exact model, connection and configuration to your setup.
THE DETAILS
Technical specifications
Wireless and Hardware
GT-BE98
WiFi 6 (802.11ax), WiFi 7 (802.11be), IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, IPv4, IPv6
BE25000 ultimate BE performance : 1376+5764+5764+11529 Mbps
2.4GHz BE: 4x4 (Tx/Rx) 4096 QAM 20/40MHz, up to 1376Mbps, 5GHz-1 BE: 4x4 (Tx/Rx) 4096 QAM 20/40/80/160MHz, up to 5764Mbps, 5GHz-2 BE: 4x4 (Tx/Rx) 4096 QAM 20/40/80/160MHz, up to 5764Mbps, 6GHz BE: 4x4 (Tx/Rx) 4096 QAM 20/40/80/160/320MHz, up to 11529Mbps
External antenna x 8
2.4GHz 4x4, 5GHz-1 4x4, 5GHz-2 4x4, 6GHz 4x4
2.6GHz quad-core processor
256 MB Flash and 2 GB RAM
OFDMA (Orthogonal Frequency Division Multiple Access) 4096-QAM high data rate 20/40/80/160/320 MHz bandwidth
2.4 GHz / 5 GHz / 6 GHz
Router(AiMesh router), AiMesh node, Access point, Repeater, Media bridge
Connections and Physical Specifications
1 x 10Gbps for WAN/LAN 1 x 2.5Gbps for WAN/LAN 1 x 10Gbps for LAN 3 x 2.5Gbps for LAN 1 x RJ45 10/100/1000Mbps for LAN 1 x USB 3.2 Gen1 1 x USB 2.0
WPS Button, Reset Button, Power Switch, LED control Button
WAN(Internet) x1 10G LAN x1 1G/2.5G LAN x1 6GHz x1 5GHz-1 x 1 5GHz-2 x 1 2.4GHz x1 Power x1
AC Input : 110V~240V(50~60Hz) DC Output : 19.5 V with max. 3.33 A current
GT-BE98 quad-band gaming router RJ-45 cable Power adapter Quick Start Guide Warranty card
2000 g
350.41 x 350.41 x 220.6 mm
Network Features
AiMesh, • Primary AiMesh Router, • AiMesh Node
Game Boost / Acceleration, WTFast, ROG_First, OpenNAT (Game Profile), Gaming Port
"Allow you to block access to unwanted websites and apps.", Parental Control Customized Internet Schedule, 64, 64
"The Guest Network provides Internet connection for guests but restricts access to your local network.", 2.4 GHz + 5 GHz : 5, Guest Network Connection time limit, Open system, WPA/WPA2/WPA3 Personal
WPA/WPA2/WPA3 Personal WPA/WPA2/WPA3 Enterprise Open System & OWE, WPS, Let's Encrypt, DNS-over-TLS, SSH, Security Scan, Firewall, 64, 32, 64
AiProtection Pro, • Router Security Assessment, • Malicious Site Blocking, • Two-Way IPS, • Infected Device Prevention and Blocking
Instant Guard, VPN Client L2TP, VPN Client Open VPN, VPN Client PPTP, VPN Client WireGuard, VPN Server IPSec, VPN Server Open VPN, VPN Server PPTP, VPN Server WireGuard, VPN Fusion
Adaptive QoS, • Bandwidth Monitor, • Bandwidth Limiter, 32, Traditional QoS, Traffic Monitor, • Real-time Traffic Monitor, • Wired Traffic Monitor, • Wireless Traffic Monitor, Traffic Analyzer, Daily, Weekly, Monthly, • Website History
Automatic IP, Static IP, PPPoE, PPTP, L2TP, Dual WAN, 3G / 4G LTE Dongle, 4G / 5G Auto Mobile Tethering, Port Forwarding, 64, Port Triggering, 32, DMZ, DDNS, PPTP, L2TP, IPSec, RTSP, H.323, SIP Passthrough,PPPoE relay
DHCP Server, IPTV, LAN Link Aggregation, Manually Assign IP Address, 128, Wake on LAN (WOL)
MU-MIMO, UTF-8 SSID, WiFi MAC Address Filter, 64, Wireless Scheduler, Airtime Fairness, RADIUS Client
4G / 5G Auto Mobile Tethering, HFS+, NTFS, vFAT, ext2, ext3, ext4, Safely Remove Disk, AiCloud, Download Master, AiDisk, Media Server, Time Machine, Samba Server, FTP Server, Shared Folder Privileges
ASUSWRT
Configuration Backup and Restore, Diagnosis Tools, Feedback System, System Log, New Device Connect Notification, Login Captcha, Connection Diagnosis, Auto Firmware Update
