AVerMedia Live Gamer HD 2 Full HD PCIe Capture Card
Record and stream Full HD gameplay with AVerMedia Live Gamer HD 2 GC570. This internal PCIe card supports 1080p60 capture and passthrough, with HDMI and 3.5 mm audio connections.
Regular price
46.000 KWD
or 4 payments of 11.500 KWD with
Pay with card & save
44.000 KWD
Save 2.000 KWD
Overview
AVERMEDIA LIVE GAMER HD 2 FULL HD PCIE CAPTURE CARD
AVerMedia Live Gamer HD 2
AVerMedia Live Gamer HD 2: Keep your capture hardware inside your desktop, ready for streaming and recording sessions. Available from AX Store in Kuwait.
PCIe Gen 2 ×1
Desktop Interface
1080p60
Capture / Passthrough
HDMI + 3.5 mm
Audio Routes
Windows
Compatible Recording Host
Smooth 1080p60 gameplay
HDMI passthrough feeds your display while you record. Connect an unencrypted HDMI source and use compatible software such as OBS. Match the actual host, connection and selected operating mode, then check the result with the equipment and settings you intend to use for the session.
Flexible audio routing
HDMI audio and 3.5 mm analogue inputs and outputs give your setup more connection options. Match the actual host, connection and selected operating mode, then check the result with the equipment and settings you intend to use for the session.
Choose the Internal Desktop Route
GC570 Live Gamer HD 2 is an internal PCIe Gen 2 ×1 card for a compatible Windows desktop. Capture and passthrough reach 1080p60. HDMI and three-pole 3.5 mm audio connections have defined input/output roles; HDCP-protected signals are not supported.
Match the Capture Signal and Passthrough Display
Connect the supported HDMI source to the card input and use the HDMI output for the display route. Choose a format accepted by the source, card and display, checking recording settings separately from passthrough.
Plan the Recording Computer Before Installation
Live Gamer HD 2 uses a PCIe Gen 2 ×1 connection inside a compatible Windows desktop. Check the available slot and surrounding card clearance, then configure supported software for the intended Full HD recording workflow.
Check the Audio Alongside the Picture
Set the recording application’s video and audio sources for the actual connected signal. Monitor a short test clip for picture, sound and synchronisation, using a supported unprotected source before starting the longer capture session.
Build the Video and Commentary Route
Choose the source connection and computer connection for this exact capture device. Plan display routing separately where needed, and select a microphone and monitoring arrangement for your own commentary. Compare related options such as AVerMedia Live Gamer Portable 2 PLUS Capture Device or AVerMedia GC573 Live Gamer 4K Capture Card, 2160p@60Hz HDR, keeping the exact model and configuration in the decision. For the wider setup, explore Logitech Blue Snowball iCE USB Microphone - Black / White and check the connection, size or mounting requirements before pairing accessories. Browse the AVerMedia range at AX for more choices.
AVerMedia Live Gamer HD 2 Setup Choices
Choose the source connection and computer connection for this exact capture device. Plan display routing separately where needed, and select a microphone and monitoring arrangement for your own commentary. Explore Elgato Wave 3 MK.2 USB Condenser Microphone - Wave FX / Black, Elgato Stream Deck MK.2, 15-Key Customizable Controller, Razer Key Light Chroma - All-In-One Lighting Kit.
Frequently Asked Questions
What should I check for this exact model?
GC570 Live Gamer HD 2 is an internal PCIe Gen 2 ×1 card for a compatible Windows desktop. Capture and passthrough reach 1080p60. HDMI and three-pole 3.5 mm audio connections have defined input/output roles; HDCP-protected signals are not supported.
Can I plug this card into a laptop USB port?
No. It is an internal PCIe card for a compatible Windows desktop with a suitable slot, system resources and installation clearance. USB capture devices use a different interface.
Will the highest mode work with any computer or HDMI source?
The source signal, capture settings, display, software and computer performance must support the selected mode. Check the complete system requirements and distinguish capture format from the output display’s capabilities.
Can it capture HDCP-protected services?
HDCP-protected signals are not supported. Use a supported unprotected video source and the settings permitted by that device’s manufacturer.
Build Your Setup with AX Store
Explore computers, displays and accessories for your workspace at AX Store. For help choosing the right model or checking an accessory, contact AX Store.
THE DETAILS
Technical specifications
Capture
GC570
PCI-Express Gen 2 ×1
Up to 1920 × 1080 at 60 fps
HDMI input and output
HDMI and 3-pole 3.5 mm input/output
Windows 10 / 11
HDCP not supported
Physical
125 × 151 × 21.5 mm
145 g
