GameMax
GameMax VEGA Pro E-ATX Full Tower Case with ARGB Fan, Grey
GAMEMAX Vega Pro M909 Grey combines metal-Panel Styling and Glass Sides with E-ATX Support. Grey metal front and top panels frame the Vega Pro’s glass-sided presentation, with a black interior for the hardware.
Regular price
24.500 KWD
or 4 payments of 6.125 KWD with
Pay with card & save
23.500 KWD
Save 1.000 KWD
Overview
GAMEMAX VEGA PRO M909 GREY
Metal-Panel Styling and Glass Sides with E-ATX Support
GAMEMAX Vega Pro M909 Grey combines metal-Panel Styling and Glass Sides with E-ATX Support. Grey metal front and top panels frame the Vega Pro’s glass-sided presentation, with a black interior for the hardware.
360 mm
GPU length clearance
170 mm
CPU-cooler clearance
360 mm
Top radiator option
1 rear fan
Factory cooling package
The Chassis Design
Grey metal front and top panels frame the Vega Pro’s glass-sided presentation, with a black interior for the hardware. The full exterior measures 480 L × 227 W × 515 H mm around the manufacturer’s full-tower arrangement. Consider its complete exterior dimensions alongside the available desk or floor space, leaving access for the rear cables and the panels used during assembly.
Included Cooling and Lighting
One 120 mm rear fan is included. Front and upper fans are optional additions, while the Rainbow V1.7 control arrangement supports up to six compatible fans. The visible lighting system should not be read as a factory-installed six-fan bundle. Connect fan power and any separate lighting leads to their specified interfaces. Choose additional cooling around the installed components and the positions that remain available.
Radiator and Fan Positions
The top accepts three 120 mm or two 140 mm fans, with two 120 mm front positions. Radiator options include 360 or 280 mm at the top, 240 mm at the front and 120 mm at the rear. Plan one compatible assembly for each mounting position, accounting for the full fan-and-radiator thickness around memory, motherboard connections and adjacent cooling hardware.
Motherboard and Component Fit
Motherboard support extends to E-ATX at 330 × 305 mm, alongside ATX, Micro-ATX and Mini-ITX. Graphics-card length clearance is 360 mm and CPU-cooler height clearance is 170 mm, with the power supply mounted in the standard ATX arrangement. Compare complete component dimensions, including protruding plugs and graphics power cables, before securing the final mounting positions. The listed clearances describe individual limits rather than every possible combined installation.
Storage, Access and Routing
The drive layout provides three 3.5-inch HDD positions and four 2.5-inch SSD positions. The rear cable area has a listed depth of 20 mm, so organise the larger cable groups before closing the side panel over the completed storage and power connections. Position the selected drives together with the power and data leads, keeping the cooling paths clear. Leave enough slack at the connectors to remove the relevant panels for maintenance.
Model
GAMEMAX Vega Pro M909 Grey
Case size
Full Tower
Motherboard support
E-ATX / ATX / Micro-ATX / Mini-ITX
Everyday Connections
Two USB-A 3.0 ports, two USB 2.0 ports and separate audio connections provide front access. The Rainbow controller is used with the specified compatible fan wiring; connect its control arrangement according to the supplied case instructions. Route the internal front-panel leads to the corresponding motherboard headers during assembly. USB performance and available lighting-control features depend on the connected host hardware and supported control arrangement.
Complete Your Workspace
Explore PC Cases to compare suitable options and complete your setup.
Frequently Asked Questions
Which motherboard formats fit GAMEMAX Vega Pro M909 Grey?
E-ATX / ATX / Micro-ATX / Mini-ITX.
Which fans are included?
1 × 120 mm rear; other positions optional.
What graphics-card length fits?
360 mm.
What CPU-cooler height fits?
170 mm.
Which radiator positions are available?
Top: 360 / 280 mm; front: 240 mm; rear: 120 mm.
Which front connections are available?
2 × USB-A 3.0; 2 × USB 2.0; audio.
Build Your Setup with AX Store Kuwait
Explore computers, displays and accessories for your workspace at AX Store Kuwait. For help choosing the right model or checking an accessory, contact AX Store.
THE DETAILS
Technical specifications
Case Hardware
GAMEMAX Vega Pro M909 Grey
Full Tower
E-ATX / ATX / Micro-ATX / Mini-ITX
M909 Vega Pro Grey
480 L × 227 W × 515 H mm
Black
330 × 305 mm
1 × 120 mm rear; other positions optional
360 mm
170 mm
Top: 360 / 280 mm; front: 240 mm; rear: 120 mm
Front: 2 × 120 mm; top: 3 × 120 or 2 × 140 mm; rear: 120 mm
Rainbow V1.7; up to 6 compatible fans
3 × HDD; 4 × SSD
20 mm
2 × USB-A 3.0; 2 × USB 2.0; audio
