LIAN LI O11 Dynamic EVO XL Full Tower Case
The LIAN LI O11 Dynamic EVO XL combines a reversible dual-chamber layout with an adjustable motherboard tray. A removable front pillar opens the glass display, while top, side and bottom mounting positions support radiators up to 420 mm.
Color
Regular price
63.000 KWD
or 4 payments of 15.750 KWD with
Pay with card & save
60.000 KWD
Save 3.000 KWD
Overview
LIAN LI O11 DYNAMIC EVO XL
LIAN LI O11 Dynamic EVO XL
The LIAN LI O11 Dynamic EVO XL combines a reversible dual-chamber layout with an adjustable motherboard tray. A removable front pillar opens the glass display, while top, side and bottom mounting positions support radiators up to 420 mm. Available from AX Store in Kuwait.
3 × 420 mm
Radiator mounting potential
460 mm
GPU length clearance
3 positions
Motherboard-tray height
Reversible
Case layout
A Larger Reversible O11 Layout
The case can be built in normal or reversed mode to present the hardware from the required side. Its aluminium, steel and tempered-glass body measures 522 D × 304 W × 531.9 H mm. Choose the orientation before arranging the motherboard tray, cooling brackets, drive cages and cable paths.
A Clear View through the Glass
The front pillar can be removed to create an uninterrupted view across the glass panels once the system is installed. Keep the pillar fixed in position during transport, as specified by the manufacturer. The front ARGB strip adds a configurable lighting accent around the hardware display.
Three 420 mm Radiator Positions
The top, side and bottom each accept a radiator up to 420 mm, with alternative smaller sizes listed for those positions. Removable cooling brackets simplify assembly, while the side bracket can face in either direction. Check combined radiator-and-fan thickness and clearance between cooling components before selecting a complete loop layout.
Adjustable Motherboard Tray
The motherboard tray can move between three height positions to change the available room for fans and radiators. Supported boards extend to E-ATX under 280 mm wide, with GPU length clearance up to 460 mm and CPU-cooler height clearance up to 167 mm. Select the tray position around the complete component layout.
Storage behind the Main Chamber
The rear chamber provides three SSD positions on the cable-management bar and four additional drive positions in the cages. Supported alternatives include seven SSDs or four HDDs together with three SSDs. Swinging cages and removable routing parts provide access, with storage placement chosen alongside the power and cooling arrangement.
Dimensions
522 D × 304 W × 531.9 H mm
Maximum GPU length
460 mm
Maximum CPU-cooler height
167 mm
Relocatable Ports and Cable Guides
A modular I/O assembly provides four USB-A ports, USB-C and audio, with positions around the lower case to suit the installation. Dual-layer cable clips and straps help organise the second chamber. For reversed layouts, confirm that the required audio-extension lead is supplied or available for the chosen cable route.
Plan the Component Clearances
Check motherboard format, graphics-card length, cooler height and radiator positions together. Allow space for the power supply and cable routing before selecting the rest of the build. Compare related options such as Lian LI O11 Dynamic Mid Tower Case, Tempered Glass or XIGMATEK Aquarius S Mid Tower Case, keeping the exact model and configuration in the decision. For the wider setup, explore LIAN LI UNI FAN TL LCD FLEX Reverse Blade Wireless 120mm ARGB Fan - 1 Pack and check the connection, size or mounting requirements before pairing accessories. Browse the Lian LI range at AX for more choices.
LIAN LI O11 Dynamic EVO XL Setup Choices
Check motherboard format, graphics-card length, cooler height and radiator positions together. Allow space for the power supply and cable routing before selecting the rest of the build. Explore Corsair RMe Series RM750e Fully Modular Low-Noise Power Supply, Corsair iCUE SP120 RGB ELITE Performance 120mm Triple Fan Pack.
Frequently Asked Questions
Which motherboards are supported?
E-ATX / ATX / Micro-ATX / Mini-ITX. Check the listed board-width and component-clearance limits.
What should I check for cooling?
Use the listed fan and radiator positions, allowing for the complete fan-and-radiator thickness and nearby hardware.
Is a vertical GPU kit included?
Vertical or upright GPU accessories are separate unless specifically listed as supplied.
How should I plan component clearance?
Compare the graphics card, CPU cooler, power supply and cable routing with the case’s dimensions and selected installation layout.
Build Your Setup with AX Store
Explore computers, displays and accessories for your workspace at AX Store. For help choosing the right model or checking an accessory, contact AX Store.
Compare Lian LI Front Mesh Kit for O11D EVO XL, Black. Match the exact model, connection and configuration to your setup.
THE DETAILS
Technical specifications
Case Hardware
LIAN LI O11 Dynamic EVO XL
Full Tower
E-ATX / ATX / Micro-ATX / Mini-ITX
522 D × 304 W × 531.9 H mm
460 mm
167 mm
Under 280 mm
ATX; under 220 mm
Up to 420 mm at top, side and bottom; subject to assembly clearance
7 × SSD; or 4 × HDD + 3 × SSD
4 × USB-A; USB-C; audio
3 positions
